CABLE & PIPE LOCATOR AG-309.15G
AG-309.15G is high-precision utility locating instrument. This utility locator features large LCD display which indicates actual position of cable or pipe. Moreover, after locating the position, an operator can measure burial depth of located utility without pressing any buttons and store GPS coordinates of located utility. This model is equipped with 20W transmitter. It is twice powerful in comparison to other brands.
·
Sensitivity: 100?A.
·
Direct digital measurement of
cable current up to 10 amperes.
·
Active frequency:
512/1024/8192/32768 Hz.
·
Direct digital measurement of
the current.
·
GPS/GLONASS module for accurate
positioning of the located utility.
·
Mini-USB cable and desktop
software for uploading and processing the data from the receiver.
·
Location of non-conductive and
non-metallic utilities with optional pushing rod and pipe sonde.
·
Three modes of operation:
"ROUTE”, "GRAPHIC”, “FRIEND-OR-FOE”.
·
Indication of the deviation
from the utility axis in the mode “ROUTE”.
